The smaller mobile crusher is the perfect machine for all small to moderate crushing projects where construction and demolition “waste” materials can be recycled on-site, providing a great solution for builders, landscape gardening, recycling, demolition, infrastructure, relief aid and medium sized aggregate crushing applications.
|
Model |
OP-35A |
OP-35G |
OP-50A |
OP-50G |
|
Dimensions (mm) |
3801*1500*1932 |
3300*1250*2250 |
4570*1820*2225 |
3780*1250*2250 |
|
Weight(kg) |
4200 |
3200/3500 |
5300 |
3700/4000 |
|
Throughput (t/h) |
10-60 |
10-50 |
20-80 |
20-60 |
|
Feed Port Size (mm) |
320*560 |
320*560 |
450*590 |
450*590 |
|
Output Size(mm) |
0-60 |
0-100 |
0-70 |
0-100 |
|
Max. input Size (mm) |
≤250 |
≤300 |
≤380 |
≤380 |
|
Feeding Height(mm) |
1932 |
2250 |
2180 |
2250 |
|
Discharge Height (mm) |
1100 |
1250 |
1250 |
1350 |
|
Engine(kw) |
Yanmar 37 |
External power supply |
Cummins 93 |
External power supply |
|
Walking (mm) |
250*1521（Track） |
Wheeled/ Track |
300*2299（Track） |
Wheeled/ Track |
|
Transmission |
Crusher hydraulic driven |
/ |
Crusher hydraulic driven |
/ |
Product Applications
This smaller mobile crusher is the ideal solution for recycling your demolition waste. It can crush concrete, blocks, precast blocks, asphalt pavement, limestone, slabs, curbstones, and any other type of construction waste.
Shandong Mingde Machinery is a world-renowned enterprise engaged in the research and development, manufacturing, sales and after-sales service of multi-functional attachments, mobile crushers, intelligent robots and other series of products. The company currently has 400 employees, a plant area of 60,000 square meters, more than 200 processing equipment and automatic welding equipment, and about 30 testing and inspection equipment. Mingde is committed to providing customers with high-quality series of products and diversified construction solutions. The main products are more than 80 series and 2,000 specifications and models, such as buckets, jaw crusher buckets, rotary screening buckets, crushing screening buckets, hydraulic shears, multi-functional grapples, multi-functional vibrating compactors, felling machines, universal quick hitch, drum cutters, special modified long reach arms , etc. Customers cover more than 100 countries and regions. Mingde provide OEM products for world-renowned original equipment manufacturers and sellers. By cooperating with ORNATE and ROBOT, Mingde is developing and manufacturing mobile crushers and intelligent robots and other series of equipment.
Shandong Mingde is the leading crusher bucket manufacturer in China. Provide you with a visual production line, support online video factory audits at any time, and update the production process.
1.Standard wooden pallet, wooden case, steel pallet or as customer's request.
2.Fast delivery time: 5-7 days for small quantity, and 20-30 days for container quantity.
3.Shandong Mingde have a team specialized into packing and loading container, they have rich experience, to help customer save ocean freight.
Smaller mobile crusher
